Importing necessary libraries

import numpy as np
import pandas as pd
import matplotlib.pyplot as plt
import warnings
import seaborn as sns
from sklearn.model_selection import train_test_split
from sklearn.tree import DecisionTreeClassifier
from sklearn.metrics import accuracy_score, confusion_matrix, classification_report
from sklearn.linear_model import LogisticRegression
from sklearn.ensemble import RandomForestClassifier
from sklearn.svm import SVC
import gc

warnings.filterwarnings("ignore")
plt.style.use("seaborn-v0_8")

Loading the cleaned dataset from our previous work

df = pd.read_csv('data/titanic_cleaned.csv')
df.head()

	passengerid	survived	pclass	name	sex	age	sibsp	parch	ticket	fare	embarked	title
0	1	0	3	Braund, Mr. Owen Harris	male	22.0	1	0	A/5 21171	7.2500	S	Mr
1	2	1	1	Cumings, Mrs. John Bradley (Florence Briggs Th...	female	38.0	1	0	PC 17599	71.2833	C	Mrs
2	3	1	3	Heikkinen, Miss. Laina	female	26.0	0	0	STON/O2. 3101282	7.9250	S	Miss
3	4	1	1	Futrelle, Mrs. Jacques Heath (Lily May Peel)	female	35.0	1	0	113803	53.1000	S	Mrs
4	5	0	3	Allen, Mr. William Henry	male	35.0	0	0	373450	8.0500	S	Mr

Feature Selection

print("*" * 100)
print("Features Information")
display(df.info())
print("*" * 100)
print("Unique Values in Each Column")
display(df.nunique())
print("*" * 100)
print("Descriptive Statistics")
display(df.describe())
print("*" * 100)

****************************************************************************************************
Features Information
<class 'pandas.core.frame.DataFrame'>
RangeIndex: 891 entries, 0 to 890
Data columns (total 12 columns):
 #   Column       Non-Null Count  Dtype
---  ------       --------------  -----
 0   passengerid  891 non-null    int64
 1   survived     891 non-null    int64
 2   pclass       891 non-null    int64
 3   name         891 non-null    object
 4   sex          891 non-null    object
 5   age          891 non-null    float64
 6   sibsp        891 non-null    int64
 7   parch        891 non-null    int64
 8   ticket       891 non-null    object
 9   fare         891 non-null    float64
 10  embarked     891 non-null    object
 11  title        891 non-null    object
dtypes: float64(2), int64(5), object(5)
memory usage: 83.7+ KB

None

****************************************************************************************************
Unique Values in Each Column

passengerid    891
survived         2
pclass           3
name           891
sex              2
age             88
sibsp            7
parch            7
ticket         681
fare           248
embarked         3
title            5
dtype: int64

****************************************************************************************************
Descriptive Statistics

	passengerid	survived	pclass	age	sibsp	parch	fare
count	891.000000	891.000000	891.000000	891.000000	891.000000	891.000000	891.000000
mean	446.000000	0.383838	2.308642	29.659001	0.523008	0.381594	32.204208
std	257.353842	0.486592	0.836071	13.289967	1.102743	0.806057	49.693429
min	1.000000	0.000000	1.000000	0.420000	0.000000	0.000000	0.000000
25%	223.500000	0.000000	2.000000	21.000000	0.000000	0.000000	7.910400
50%	446.000000	0.000000	3.000000	30.000000	0.000000	0.000000	14.454200
75%	668.500000	1.000000	3.000000	35.000000	1.000000	0.000000	31.000000
max	891.000000	1.000000	3.000000	80.000000	8.000000	6.000000	512.329200

****************************************************************************************************

Dependent VS Independent Variables

Testing the Feature Relevance using Chi-Square Test

from scipy.stats import chi2_contingency

# Perform Chi-Squared Test for Categorical Features

for feat in ["pclass", "sex", "embarked", "title", "ticket"]:
    df[feat] = df[feat].astype("category")
    contingency_table = pd.crosstab(df[feat], df["survived"])
    display(pd.DataFrame(contingency_table))
    chi2, p, dof, expected = chi2_contingency(contingency_table)
    print(f"Chi2: {chi2}, p-value: {p}")
    if feat != "ticket":
        sns.countplot(data=df, x=feat, hue="survived")
        plt.title(f"Survival Count by {feat}")
        plt.show()

survived	0	1
pclass
1	80	136
2	97	87
3	372	119

Chi2: 102.88898875696056, p-value: 4.549251711298793e-23

survived	0	1
sex
female	81	233
male	468	109

Chi2: 260.71702016732104, p-value: 1.1973570627755645e-58

survived	0	1
embarked
C	75	93
Q	47	30
S	427	219

Chi2: 25.964452881874784, p-value: 2.3008626481449577e-06

survived	0	1
title
Master	17	23
Miss	55	129
Mr	437	82
Mrs	26	103
Officer	14	5

Chi2: 291.3420130772467, p-value: 7.984173381155626e-62

survived	0	1
ticket
110152	0	3
110413	1	2
110465	2	0
110564	0	1
110813	0	1
...	...	...
W./C. 6608	4	0
W./C. 6609	1	0
W.E.P. 5734	1	0
W/C 14208	1	0
WE/P 5735	1	1

681 rows × 2 columns

Chi2: 766.5697029458893, p-value: 0.01152729601163775

Split the data into features and target variable Dependent Vs Independent Variables

X = df[["sex", "age", "fare", "pclass", "sibsp", "parch", "embarked", "title"]]
y = df["survived"]

print("X: ", X.shape)
print("y: ", y.shape)

X:  (891, 8)
y:  (891,)

X.info()

<class 'pandas.core.frame.DataFrame'>
RangeIndex: 891 entries, 0 to 890
Data columns (total 8 columns):
 #   Column    Non-Null Count  Dtype
---  ------    --------------  -----
 0   sex       891 non-null    category
 1   age       891 non-null    float64
 2   fare      891 non-null    float64
 3   pclass    891 non-null    category
 4   sibsp     891 non-null    int64
 5   parch     891 non-null    int64
 6   embarked  891 non-null    category
 7   title     891 non-null    category
dtypes: category(4), float64(2), int64(2)
memory usage: 32.0 KB

We need to convert categorical variables into numerical format

from sklearn.pipeline import Pipeline
from sklearn.impute import SimpleImputer
from sklearn.preprocessing import OneHotEncoder, StandardScaler
from sklearn.compose import ColumnTransformer

numerical_cols = X.select_dtypes(include=["int64", "float64"]).columns
print(numerical_cols)  # ['age', 'fare', 'sibsp', 'parch']
categorical_cols = X.select_dtypes("category").columns
print(categorical_cols)  # ['sex', 'pclass', 'embarked', 'title']

Index(['age', 'fare', 'sibsp', 'parch'], dtype='object')
Index(['sex', 'pclass', 'embarked', 'title'], dtype='object')

categorical_pipeline = Pipeline(
    [
        ("imputer", SimpleImputer(strategy="most_frequent")),
        ("encoder", OneHotEncoder(drop="first", handle_unknown="ignore")),
    ]
)
numerical_pipeline = Pipeline(
    [
        ("imputer", SimpleImputer(strategy="mean")),
        (
            "scaler",
            StandardScaler(),
        ),
    ]
)
preprocessor = ColumnTransformer(
    transformers=[
        ("num", numerical_pipeline, numerical_cols),
        ("cat", categorical_pipeline, categorical_cols),
    ]
)

# Final pipeline
model_pipeline = Pipeline(
    steps=[
        ("preprocessing", preprocessor),
        # ("classifier", RandomForestClassifier(random_state=42)),
        ("classifier", LogisticRegression(random_state=42)),
        # ("classifier", DecisionTreeClassifier(random_state=42)),
    ]
)

model_pipeline

Pipeline(steps=[('preprocessing',
                 ColumnTransformer(transformers=[('num',
                                                  Pipeline(steps=[('imputer',
                                                                   SimpleImputer()),
                                                                  ('scaler',
                                                                   StandardScaler())]),
                                                  Index(['age', 'fare', 'sibsp', 'parch'], dtype='object')),
                                                 ('cat',
                                                  Pipeline(steps=[('imputer',
                                                                   SimpleImputer(strategy='most_frequent')),
                                                                  ('encoder',
                                                                   OneHotEncoder(drop='first',
                                                                                 handle_unknown='ignore'))]),
                                                  Index(['sex', 'pclass', 'embarked', 'title'], dtype='object'))])),
                ('classifier', LogisticRegression(random_state=42))])

In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.

Split the data into features and target variable

### Split the data into features and target variable
X_train, X_test, y_train, y_test = train_test_split(
    X,
    y,
    test_size=0.2,
    random_state=42,
    stratify=y,
)
print(X_train.shape, X_test.shape, y_train.shape, y_test.shape)
gc.collect()

(712, 8) (179, 8) (712,) (179,)

0

model = model_pipeline.named_steps["classifier"]
model

LogisticRegression(random_state=42)

In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.

Applying preprocessing steps and fitting the model

X_train_processed = preprocessor.fit_transform(X_train)
X_test_processed = preprocessor.transform(X_test)

encoded_columns = (
    model_pipeline[0]
    .transformers_[1][1]
    .named_steps["encoder"]
    .get_feature_names_out(categorical_cols)
)
# Combine the numerical columns and encoded categorical columns
all_columns = list(numerical_cols) + list(encoded_columns)

# Convert to DataFrame
X_train_df = pd.DataFrame(X_train_processed, columns=all_columns)
X_test_df = pd.DataFrame(X_test_processed, columns=all_columns)
X_train_df.head(10)

	age	fare	sibsp	parch	sex_male	pclass_2	pclass_3	embarked_Q	embarked_S	title_Miss	title_Mr	title_Mrs	title_Officer
0	0.166879	0.513812	-0.465084	-0.466183	1.0	0.0	1.0	0.0	1.0	0.0	1.0	0.0	0.0
1	0.166879	-0.662563	-0.465084	-0.466183	1.0	1.0	0.0	0.0	1.0	0.0	1.0	0.0	0.0
2	0.166879	3.955399	-0.465084	-0.466183	1.0	0.0	0.0	0.0	1.0	0.0	1.0	0.0	0.0
3	-0.887551	-0.467874	-0.465084	0.727782	0.0	0.0	1.0	0.0	1.0	0.0	0.0	1.0	0.0
4	0.091562	-0.115977	0.478335	0.727782	0.0	1.0	0.0	0.0	1.0	0.0	0.0	1.0	0.0
5	-0.661602	-0.486962	-0.465084	-0.466183	1.0	0.0	1.0	0.0	1.0	0.0	1.0	0.0	0.0
6	-0.285020	0.513812	-0.465084	-0.466183	1.0	0.0	1.0	0.0	1.0	0.0	1.0	0.0	0.0
7	0.166879	4.075040	-0.465084	-0.466183	1.0	0.0	0.0	0.0	0.0	0.0	1.0	0.0	0.0
8	0.166879	-0.501190	-0.465084	-0.466183	1.0	0.0	1.0	1.0	0.0	0.0	1.0	0.0	0.0
9	0.091562	-0.287761	0.478335	-0.466183	0.0	0.0	1.0	0.0	1.0	0.0	0.0	1.0	0.0

model.fit(X_train_df, y_train)

LogisticRegression(random_state=42)

In a Jupyter environment, please rerun this cell to show the HTML representation or trust the notebook.
On GitHub, the HTML representation is unable to render, please try loading this page with nbviewer.org.

Generating Predictions on Test Data

y_pred = model_pipeline.predict(X_test)
y_proba = model_pipeline.predict_proba(X_test)[:, 1]
print(y_pred[:10])
print(y_proba[:10])

[0 0 0 0 1 1 1 0 0 0]
[0.05099579 0.04055293 0.15135114 0.02703658 0.66735637 0.60975207
 0.7190783  0.49081549 0.26258101 0.12986952]

Evaluating the Model

from sklearn.metrics import (
    classification_report,
    confusion_matrix,
    accuracy_score,
    roc_curve,
    roc_auc_score,
    precision_recall_curve,
    average_precision_score,
)

print("Classification Report: \n", classification_report(y_test, y_pred))
print("Model Accuracy: ", f"{accuracy_score(y_test, y_pred) * 100:.2f}%")

Classification Report:
               precision    recall  f1-score   support

           0       0.84      0.90      0.87       110
           1       0.82      0.72      0.77        69

    accuracy                           0.83       179
   macro avg       0.83      0.81      0.82       179
weighted avg       0.83      0.83      0.83       179

Model Accuracy:  83.24%

cm = confusion_matrix(y_test, y_pred)
class_names = ["Not Survived", "Survived"]

# Plot
plt.figure(figsize=(8, 6))
sns.heatmap(
    cm,
    annot=True,
    fmt="d",
    cmap="Blues",
    xticklabels=class_names,
    yticklabels=class_names,
)

plt.xlabel("Predicted")
plt.ylabel("Actual")
plt.title("Confusion Matrix")
plt.tight_layout()
plt.show()

fpr, tpr, thresholds = roc_curve(y_test, y_proba)
auc = roc_auc_score(y_test, y_proba)

plt.figure()
plt.plot(fpr, tpr, label=f"AUC = {auc:.2f}")
plt.plot([0, 1], [0, 1], 'k--')
plt.xlabel("False Positive Rate")
plt.ylabel("True Positive Rate")
plt.title("ROC Curve")
plt.legend()
plt.grid(True)
plt.show()

precision, recall, _ = precision_recall_curve(y_test, y_proba)
avg_precision = average_precision_score(y_test, y_proba)

plt.figure()
plt.plot(recall, precision, label=f"Avg Precision = {avg_precision:.2f}")
plt.plot([1, 0], [0, 1], 'k--')
plt.xlabel("Recall")
plt.ylabel("Precision")
plt.title("Precision-Recall Curve")
plt.legend()
plt.grid(True)
plt.show()

Saving the model

# import pickle

# # Save the pipeline to a file
# with open("models/model_pipeline.pkl", "wb") as f:
#     pickle.dump(model_pipeline, f)

Loading the model

X[:20]

	sex	age	fare	pclass	sibsp	parch	embarked	title
0	male	22.0	7.2500	3	1	0	S	Mr
1	female	38.0	71.2833	1	1	0	C	Mrs
2	female	26.0	7.9250	3	0	0	S	Miss
3	female	35.0	53.1000	1	1	0	S	Mrs
4	male	35.0	8.0500	3	0	0	S	Mr
5	male	32.0	8.4583	3	0	0	Q	Mr
6	male	54.0	51.8625	1	0	0	S	Mr
7	male	2.0	21.0750	3	3	1	S	Master
8	female	27.0	11.1333	3	0	2	S	Mrs
9	female	14.0	30.0708	2	1	0	C	Mrs
10	female	4.0	16.7000	3	1	1	S	Miss
11	female	58.0	26.5500	1	0	0	S	Miss
12	male	20.0	8.0500	3	0	0	S	Mr
13	male	39.0	31.2750	3	1	5	S	Mr
14	female	14.0	7.8542	3	0	0	S	Miss
15	female	55.0	16.0000	2	0	0	S	Mrs
16	male	2.0	29.1250	3	4	1	Q	Master
17	male	32.0	13.0000	2	0	0	S	Mr
18	female	31.0	18.0000	3	1	0	S	Mrs
19	female	35.0	7.2250	3	0	0	C	Mrs

# import pickle

# loaded_model = pickle.load(open("models/model_pipeline.pkl", "rb"))

# # Use it for prediction
# print("Model Predictions: ", loaded_model.predict(X[:20]))
# print("Original Labels: ", y[:20].values)
# print("Model Probabilities: ", loaded_model.predict_proba(X[:20])[:, 1])
# print("Model Score: ", loaded_model.score(X[:20], y[:20]))

Model Predictions:  [0 1 1 1 0 0 0 0 1 1 1 1 0 0 0 1 0 0 0 1]
Original Labels:  [0 1 1 1 0 0 0 0 1 1 1 1 0 0 0 1 0 1 0 1]
Model Probabilities:  [0.08       0.99       0.7        1.         0.02170042 0.00333333
 0.03       0.12       0.88       0.98       0.91       0.77
 0.099      0.02       0.09       0.94       0.16       0.436
 0.26       0.9       ]
Model Score:  0.95
